Quilting Machine Line YT-HF-8+YT-CS-3A+YT-BD-1

Quilting Machine Line

Yuantian Company is spotlighting its innovative mattress quilting, cutting, and stacking integrated machine, transforming the production process. The new-gen computer control system offers intelligent pattern correction and compensation, perfect for beginners. It features automatic thread break detection for both surfaces, automatic needle lifting for efficiency, and an optimized, high-strength mechanical structure for stable operation. Driven by a servo motor, it ensures precise, smooth quilting, followed by automatic edge locking and tidy stacking—reducing labor costs and enhancing production quality. Count on Yuantian, the choice of professionals, to revolutionize the industry!

Parameters of YT-HF-8+YT-CS-3A+YT-BD-1

YT-HF-8
Productivity	60-300m/h
Spindle speed	600-1200(RPM/min)
Sewing Needle Height	110-1230mm
X stroke	350
Sewing Thickness	≤80(AII patterns)
Sewing Width	2350mm
Stitch Length	3-8mm
Needel Mode	24/180、23/160、22/140、21/130
Needle Array Pitch	50.5, 76.2, 127(5) 76.2, 76.2, 152.4(6″)
Total Power	8.5kw
Power Supply	3Ph380v50hz
Total weight	≈5600kg
Overall Dimension	611653682558mm
YT-CS-3A
Sewing Speed	≤15m/min
Sewing Thickness	≤70mm
Sewing Width	1800-2200mm
Needel Model	Dvx59 24
Stitches Per Minute	≤2500RPM
Stitch Length	1-8mm
Power Supply	3Ph380v50hz
Total Power	8.0KW
Rated power	5.0KW
Air Pressure	0.6-0.8MPa
Total Weight	≈3200KG
Overall Dimension	522048252190mm
YT-BD-1
Stacking Speed	200pcs/h
Max Stacking Height	1800mm
Available Size of Fabric	≤ 2400mm
Total Power	2.0kw
Power Supply	3Ph380v50hz
Air Pressure	0.6-0.8MPa
Total weight	≈800kg
Overall Dimension	340035002350mm
