Mattress Tape Edge Sewing Machine YT-WB-4B
This automatic mattress tape edge sewing machine is specially designed for sewing the edge seams between the top and bottom layers of mattresses, as well as the side tape. It is not only applicable to the production of mattresses, but also to other soft bedding products, such as sleeping bags and tents.
It is equipped with an automatic flipping mechanism, which can easily complete the mattress flipping operation, simplify the sewing process, and improve production efficiency. Moreover, our mattress tape edge sewing machine can easily adapt to mattresses of different heights and thicknesses ranging from 50 to 450 millimeters, meeting various production needs.
The YT-WB-4B is renowned for its powerful performance and reliability, making it an excellent choice for mattress manufacturing.
| Productivity | 12 – 18pcs/h |
| Total Weight | ≈1300kg |
| Thickness | 50 – 450mm |
| Overall Dimension | 4050*3000*1950mm |
| Max Rotating Speed | 2000RPM (100U); 3000RPM (PUFF) |
| Table Size | 3950*2000*900mm |
| Total Power | 4.2kw |
| Standard Mattress Weight | ≤75kg |
| Power Supply | 3PH – 380v – 50Hz (Can be customized) |
| Customized for Over – Weight Mattress | ≤500kg |
| Air Pressure | 0.6 – 0.8MPa |
