Multi-Needle Mattress Tufting Machine YT-CD-4A
The mattress tufting machine, as the core equipment in the mattress tufting process, can significantly improve production efficiency and process quality.
The features of this mattress tufting machine are as follows:
1. This mattress tufting machine is equipped with a multi-needle pneumatic synchronous drive system, which can complete the operation of multiple tufting points simultaneously. Compared with the traditional point-by-point tufting method, it significantly shortens the tufting time and improves the tufting efficiency.
2. The equipment adopts advanced pneumatic drive technology, which is easy to operate and master.
3. The multi-needle mattress tufting machine is suitable for mattress sizes up to 2200 x 2200 x 450 millimeters, meeting the processing requirements of the vast majority of mattresses on the market.
4. Applicable mattress types: Independent pocket spring mattresses, sponge mattresses, latex mattresses, etc.
5. The machine is equipped with an adjustable conveyor table, making the movement and positioning of the mattress more convenient during the production process. The operator can freely adjust according to the size of the mattress to ensure a smooth and stable conveying process and reduce the difficulty of handling.
6. The tufting machine can be rotated and combined with the adjustable conveyor table to achieve flexible processing at multiple angles.
| Air Pressure Requirements | 0.6 – 0.8MPa |
| Power Supply | 380V 50/60Hz (Customizable) |
| Total Power | ≈0.55KW |
| Total Weight | ≈2.3t |
| Mattress Size | 2200×2200×450mm |
| Max Quantity of Needle | 50 |
| Needle Gauge | 150×225mm |
