line assembler Automatic High Speed Pocket Spring Machine automatic YUANTIAN Mattress Machines

line assembler Automatic High Speed Pocket Spring Machine automatic YUANTIAN Mattress Machines

Application:
Mattress, Sofa, Cushion
Model:
DT-012
Brand Name:
YUANTIAN
Place of Origin:
Guangdong, China (Mainland)
Certificates:
ISO9001 / CE
Minimum Order:
1 Set
Price Term:
FOB, C&F, CIF (optional)
Payment Terms:
 L/C T/T
Packaging Details:
Wooden Case
Delivery:
10 - 30 work days
Manganese Wire: 1.8 - 2.3mm
Spring Type: pocket spring
Non Woven Fabric: above 70g/square meter
Eco-Friendly: Eco-friendly
Warranty: 1 year
Capacity: 85 - 110 pocket springs per min
Productivity: 85〜100Pcs/min
Overall Dimension: 4320×1560×2030
Power Supply: 3Ph,380V 50HZ
Total Power: 48KW
Free Spring Height: 160〜260mm
Pocketed Spring Height: 120〜220mm
Wire Diameter: Ф1.8〜Ф2.3mm
Mid-Coil Diameter: Ф55〜Ф75mm
Non-Woven Fabric Thickness: ≥70g/m²
Non-Woven Fabric Width For Assembling: 380〜490mm
Company Advantages
1. Our key strengths are in Automatic High Speed Pocket Spring Machine production and marketing and supply of Automatic Pocket Spring Machine.It supports all its businesses with high quality research and technology.'Our products have been exported to countries all around the world
2. Use of Automatic Pocket Spring Production Line in our manufacturing process assures the optimum performance and longer life of these products. o provide a fully automatic mattress transport line with high speed, high reliability and easy maintenance
3. This Pocket spring coiling machine Automatic High Speed Pocket Spring Machine is formed to fit on spring coiling machine parts. We can provide on-site services. After customers apply service, we will send professional after-sales engineers to solve the problem.
4. Equipped with the necessary machinery according to different production processes, YUANTIAN Mattress Machines Professionally Produces And Exports Standard Automatic Pocket Spring Production Line, automatic spring coiling machine.
5. Automatic High Speed Pocket Spring Machine offers excellent performance especially if mattress spring coiling machine have to be spring coiling machine for sale. LS-320 Lockstitch Multi-Needle Mattress Quilting Machine greatly simplifies the transmission structure, prolongs the service life and reduces the maintenance cost.

DT-012  Automatic High Speed Pocket Spring Machine



This High Speed Pocket Spring Coiling Machine is with microcomputer NC, self-developed control system, ultrasonic welding, low noise, no pollution, awarded a number of patents, the best choice for the production of pocket spring.



1. With digital controlled spring coiling box, all spring size can be modified by parameterized settings without adjusting mechanism. Modular design, easy to install and steady performance.

2. Safe and reliable insulation design offers good heating treatment.

3. Fabric receiving device to make it easy to replace non-woven fabric, reduce waste and save time.

4. Greatly simplified pocket structure with high efficiency.

5. Clean ultrasonic welding to save energy.

6. Efficient and secure automatic cut-off device.


 Main Technical Parameters



Speed85100Pcs/min

Overall SizeL×W×H):4320×1560×2030

Power Supply3Ph380V 50HZ

Air Supply0.60.8MPa

Air Displacement0.8m³/min

Total Power48KW

Working Power30KW

Spring Free Height160260mm

Pocket Spring Height120220mm

Wire DiameterФ1.8Ф2.3mm

Spring Mid-Coil DiameterФ55Ф75mm

Non-Woven Fabric Width380490mm

Non-Woven Fabric Density≥70g/m²
