binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines

binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines
  • binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines

binding wb1 mattress tape edge machine table YUANTIAN Mattress Machines

Application:
Mattress, Sofa, Cushion
Model:
WB-3A
Brand Name:
YUANTIAN
Place of Origin:
Guangdong, China (Mainland)
Certificates:
ISO9001 / CE
Minimum Order:
1 Set
Price Term:
FOB, C&F, CIF (optional)
Payment Terms:
T/T, L/C
Packaging Details:
Wooden Case
Delivery:
10 - 30 work days
Productivity: 15units/h
Overall Dimension: 2380x1400x1650mm
Power Supply: 3-Phase, AC380V, 50Hz
Total Power: 1.2kw
Machine Weight: 598kg
Table Size: 2000x1600mm
Mattress Thickness: 60-430mm
Table Automatic Lifting Range: 140mm
Company Advantages
1. Smart vertical assembly model to shorten operation time, improve performance and enhance convenient operation, YUANTIAN Mattress Machines & Equipment's mattress tape edge machine, mattress tape edge machine, mattress tape edge Gains A Lot Of Awards From Customers From Both Home And Abroad.
2. Our well equipped infrastructure has capacity to develop mattress edge banding machine in desired sizes as per the demands of our clients. The sewing speed of the Mattress Flanging Machine is controlled with imported needle position motor and control box.
3. The YUANTIAN Mattress Machines china computerized single-needle and multi-functional quilting machine manufacturer features design innovations throughout the machine including a mattress tape edge sewing machine to improve mattress tape edge. LS-320 Lockstitch Multi-Needle Mattress Quilting Machine greatly simplifies the transmission structure, prolongs the service life and reduces the maintenance cost.
4. This machine needs only one operator and there is no need for him to move around or overturn the mattress manually. Thus higher efficiency and less labor is realized, We Are Provide The Latest Design multi-needle multi-functional quilting machine products, Automatic Turn Mattress Tape Edge Machine(WB-4A, mattress tape edge machine,mattress making machine, mattress sewing machine For Customers In The Global Market.
5. Furnishing of Lock stitch mattress tape edge sewing machine and Mattress Tape Edge sewing Machine makes YUANTIAN Mattress Machines edge machine user friendly in nature. The Mattress Flanging Machine is equipped with pneumatic auto presser foot, equipped with special encorder to position needles. Low noise, small vibration, stable performance.


This machine is mainly used for tape-edging of mattress panel,sleeping bag and tent.


Features


Advanced chainstitch sewing head.


Auto-lifting table,hand-controlled tilting of sewing head.


Variable speed for moving of carriage and sewing,auto-slowdown at corners.


Straight,even and attractive seam.


Equipped with level-adjusting device.



Low noise,small vibration,stable performance.



Main Technical Parmeters


Thickness of Mattress60 - 430mm
Table Lifting Range140mm
Table Size2000 * 1600mm
Overall Dimension2380*1400*1600mm
Gross Weight598kgs
Capacity15 units per hour
Total Power1.2KW
Power Supply3-Phase, 380V, 50HZ
Single HeadYes
Single NeedleYes
Moving StyleHead Move
SpeedAdjustable
Sewing Headadjustable up/down, left/right


Possible Customized Parameter:

1.Color on Machine:Blue or to order

2.Sewing Head:Chainstitch Sewing Head, CHN 300U sewing head or Taiwan 300U Sewing Head


Installation

We can offer installation, commissioning and training in buyer's factory for domestic and overseas customers.


Product Warranty

2 years, but wearing parts, consumption material and the damage incurred by the Buyer's incorrect operation are out of the warranty range.





Company Features
1. Lack Of Knowledge Is Darker Than Night. With Excellent Performance And Low Prices, The mattress tape edge machine, mattress tape edge machine, mattress tape edge sewing machine We Exported Are Welcomed By Oversea' Markets. Check Now!
2. Our professionals manufacture these mattress tape edge as per clients’ given specifications and are available in diverse attractive patterns and sizes.
